MMA Leeuwin

/sites/mmaoffshorecomau//assets/public/image/ProductListing/Leeuwin_aerial-59.jpg

Overview

The MMA Leeuwin has been a high performing marine asset for MMA operating predominately on the North West Shelf of Western Australia. The vessel was contracted to Woodside consistently over a 5 year period from its delivery in 2013 and is now supporting various Australian based operators. Designed by VARD and constructed in the ASL Shipyard Singapore, the Leeuwin features all the quality European elements and technology that is synonymous with a VARD vessel.

Enquire Today

Key Features

  • Notation:
    ✠1A1 Fire fighter(I) Clean(Design) COMF(V-3) DK(V-3) DK(+) DYNPOS(AUTR) E0 HL(2.8) LFL(*) OILREC SF
  • Built & Flag:
    The vessel was built in 2013  and operates under a Singapore Flag
  • Deck Space:
    With just over 810m2 clear deck space the vessel is ideal for cargo transportation
  • Dynamic Positioning:
    DP2 notation provides excellent manoeuvrability for close and safe interaction with offshore facilities.
  • BHP:
    Four diesel electric Cummins main engines provide over 6,434 BHP
  • Area of Operations:
    The vessel predominantly operates in Australia and New Zealand waters but can be mobilised for international operations

Vessel Summary

  • PARTICULARS
    • Vessel Type Platform Supply Vessel
    • IMO Number 9674658
    • Port of Registry Singapore
    • Year Built 2013
    • Class Det Norske Veritas - Germanischer Lloyd
    • Notation ✠1A1 Fire fighter(I) Clean(Design) COMF(V-3) DK(V-3) DK(+) DYNPOS(AUTR) E0 HL(2.8) LFL(*) OILREC SF
  • DETAILS
    • Length Overall 82.2m
    • Breadth 17.4m
    • Beam 17.0m
    • GRT-NRT 3464/1435
    • Deadweight 4000t at draught 6.3m midship
    • Depth Main deck Midship 7.6m
    • Maximum draft 6.3m
    • BHP 6434
    • Cargo deck area 810m²
    • Deck loading 10E/5E/m²
    • Max Speed 14 knots
    • Bollard Pull N/A
    • Sewage Plant MARPOL compliant
    • Joystick 1 x portable joystick TC
    • Flow Meter Fitted
  • CAPACITY
    • Fuel oil 979.3m³
    • Water ballast 1740.5m³
    • Drill water 1740.5m³
    • Dry Bulk tanks 341.8m³, 6 tanks
    • Fresh water 1066.3m³
    • Liquid mud 977.5m³
    • Brine 977.5m³
    • Base oil 254.9m³
    • Glycol 977.5m³
    • Methanol 104.6m³
  • PUMPING RATES
    • Fuel Oil 2 x F/O cargo pumps discharge rate per pump150m³/hr at 90m head
    • Drill water 2 x D/W pumps discharge rate per pump 150m³/hr at 90m head
    • Dry bulk 25.4m³/min +- 4%
    • Fresh water 2 x F/W cargo pumps discharge rate per pump 150m³/hr at 90m head
    • Liquid mud 2 x LM pumps discharge rate per pump 75m³/hr at 90m head
    • Brine Pump 75m³/hr at 90m head
    • Base oil Pump 50m³/hr at 90m head
    • Glycol Pump 75m³/hr at 90m head
    • Methanol 2 x methanol pumps discharge rate per pump 50m³/hr at 90m head
  • MACHINERY
    • Generators Cummins KTA 50 DM1, 4 x 1200ekW @ 1800 RPM
    • Emergency Generators 1 x Cummins 6CT8.3DM, 100KW @ 1800 RPM
    • Bow Thruster 2 x Brunvoll type FU-74-LTC-2000 880kW, 1190 RPM
    • Propulsion 2 x 1600kW, 2 x fixed pitch azimuth thrusters
  • ACCOMMODATION
    • Berths 6 x 1 man, 11 x 2 man
      Hospital / gymnasium / office
    • Total 28 persons
  • DECK EQUIPMENT - Tugger Winch
    • Number & Capacity 2 x 10T
  • DECK EQUIPMENT - Cargo Securing Winches/Rollers
    • Type 10 x 200mm diameter rollers
  • Other Deck Equipment
    • Crane 2 x hydraulic electric cylinder luffing jib cranes, 1 x 2 tonne and 10m reach, 1 x 3 tonne at 10m reach
    • Deck Voltage & Sockets 8 x 32 AMP reefer sockets
  • LIFESAVING
    • Life rafts 6 x 16 person life rafts
    • Rescue Boat/Davit 1 x Noreq FRB 650, 15 person plus Davit
    • Immersion Suits 34
  • FIRE FIGHTING
    • Class FiFi 1
    • Extinguishers Powder, foam and CO2
    • Fire hoses Adjacent to each of the hydrants, a 2” x 15m fire hose.
  • SPECIALIST
    • DP Class DP-2
    • DGPS 2
    • Fanbeam/CyScan Fitted
